Instrumentation that closes the loop, the first time.
Field instruments, transmitters, control loops, tubing, heat trace, calibration, and loop checks. Documented to the standard your inspector needs.
01
What's in scope
The work, in detail.
Instrumentation is where measurement meets control. The work has to be precise, traceable, and survive a hostile environment.
Field instruments
Transmitters (pressure, level, temperature, flow), switches, and analytical instruments. Mounted, oriented, and connected per ISA-5.1 and the loop sheets.
Tubing and impulse lines
Stainless tubing runs with proper slope, supports, and freeze protection. Bend radii, support spacing, and fittings to spec.
Heat trace
Self-regulating and constant-wattage heat trace with insulation, controllers, and high-limit thermostats. Documented to circuit ID for future maintenance.
Control wiring
Twisted-shielded pair to junction box, marshalling, and PLC/DCS cabinet. Drain-wire grounding at one end only. Loop integrity verified before turnover.
Calibration
Bench calibration with traceable test equipment and field verification with HART communicator or 4-20 mA simulator.
Loop checks
End-to-end loop verification: field signal -> junction box -> marshalling -> I/O card -> control room display. Recorded on loop sheets with operator sign-off.
02
Deliverables
Turnover documentation.
Calibration certificates for every instrument.
As-built loop diagrams and instrument data sheets.
Loop check sheets with operator sign-off.
Material certifications and warranty transfer.
Heat trace circuit identification and commissioning records.
03
Process
How this service runs.
01
Loop sheet review
We start at the loop sheets and instrument data sheets. If something is missing, we ask before we start.
02
Pre-mount calibration
Bench calibration of each instrument in a controlled environment, with certificates retained.
03
Field installation
Mount, tube, wire, and label each instrument. Heat trace energized only after insulation closure.
04
Loop check
Inject and verify at every stage of the loop. Operator sign-off at the control room.
05
Turnover
Loop sheets signed, certificates filed, lessons-learned shared with your maintenance group.
In the field
The work is documented, the loops close, the inspector signs.
100%
self-performed scope
24/7
turnaround support
0
recordables — last job
04
Standards
Standards this scope is built to.
ISA-5.1
Instrumentation symbols and loop identification.
ISA-RP-77.60
Industrial control panel grounding practice.
NEC Article 504
Intrinsically safe systems for classified areas.
Manufacturer specifications
We follow OEM installation requirements, not generic shortcuts.
05
More services
Related work we self-perform.
Electrical & Power Construction
Power distribution, conduit, cable tray, grounding and terminations for process environments.
Explore Electrical & Power Construction
I/O Buildings, MCCs & Control Rooms
Local Instrument Rooms, I/O buildings, MCCs and control infrastructure inside and out.
Explore I/O Buildings, MCCs & Control Rooms
Tank Terminals & Farms
Classified-area electrical and instrumentation for storage terminals and loading assets.
Explore Tank Terminals & Farms
06
FAQ
Common questions on this scope.
Yes. Bench calibration with traceable equipment and field verification with HART or loop simulator. Certificates are retained and turned over with the loop sheets.
Yes, on the field-instrument and marshalling side. We coordinate with the controls integrator on I/O card mapping and address assignment.
Yes. We sequence loop checks with your commissioning lead and adjust the schedule when a loop fails or a tag changes.
Yes. Self-regulating and constant-wattage trace with insulation, controllers, and circuit identification.
Loop sheets, calibration certificates, instrument data sheets, and a marked-up P&ID set. Delivered as a single binder or digital package.
Have an instrumentation scope coming up?
Send the basics or just the P&IDs. We will respond with next steps the same business day.
